Imaging| Sensor | 1/1.8" CMOS Image Sensor |
|---|
| Zoom | Optical 18x |
|---|
| focal length | f = 6.8 ~ 122.4mm |
|---|
| Angle of view | Horizontal : 58.4°(wide) ~ 3.2°(tele), Vertical : 35°(wide) ~ 1.9°(tele) |
|---|
| Maximum aperture ratio | F1.61 ~ F4.13 |
|---|
| Focus comtrol | Oneshot AF |
|---|
| Lens type | DC auto iris |
|---|
| Min illumination | Color : 0.01 Lux(1/30sec, 30IRE) / BW : 0 Lux(IR ON) |
|---|
| Electronic shutter speed | 1/1 ~ 1/100,000 sec |
|---|
| Day & Night | Day / Night / Auto |
|---|
| Back light compensation | BLC / HLC / WDR |
|---|
| White balance | Auto tracing white / Auto white / Manual |
|---|
| Gain Control | Auto |
|---|
| Noise reduction | Auto / Manual |
|---|
| Image stabilization | Support |
|---|
| Defog | Support |
|---|
| Image rotation | Horizontal(Mirror) / Vertical(Flip) |
|---|
Camera functions| Motion detection | 8 regions on 23x15 cells |
|---|
| Privacy masking | 8 regions (polygons of 8 points) |
|---|
| IR LED | 8 pieces, Max 80m |
|---|
| Video analytics | Motion detection, Object detection, Object tracking, Face detection, Intrusion detection
Missing object detection, Abandoned object detection, Line counting, ANPR
Vehicle speed detection, Directional detection, Defocus detection, Object blurring |
|---|
| Burn-in-OSD | Camera title, direction, user-defined
Multi-lingual (English, Korean, French, German, Spanish, Italian, Russian, Japanese
Swedish, Portuguese, Dutch, Hungarian, Finnish, Special Symbols) |
|---|
Video| Compression | H.264 / H.265 / MJPEG |
|---|
| Frame rate | Max 30fps @ 3840x2160 |
|---|
| Bitrate | Primary: 32Kbps ~ 16Mbps, Secondary: 32Kbps ~ 4Mbps |
|---|
| Bitrate control | H.264/H.265: CBR / VBR / Hybrid, MJPEG: VBR |
|---|
| Resolutions | 3840x2160 ~ 352x240 |
|---|
| Streaming | Quad Streaming
Primary : H.264 / H.265, Secondary x 3 : H.264 / H.265 / MJPEG |
|---|
Audio| Compression | G.711 u-law |
|---|
| Sampling rate | G.711: 8KHz |
|---|
| Bitrate | G.711: 64Kbps |
|---|
| Streaming | Full-duplex |
|---|
| Input & Output | 1 x Line-In (mono), 1 x Line-Out (mono) |
|---|
Event and Alarm| Event sources | Video analytics, Audio detection, Client disconnection, Sensor input, Shock detection, User-defined event |
|---|
| Event actions | E-mail notification, OSD alert, FTP upload, PTZ preset, Alarm control, Recording, HTTP action |
|---|
Network| Interface | Ethernet 10/100/1000 base-T (RJ-45) |
|---|
| Protocol | IPv4/v6, TCP, UDP, IGMP(Multicast), ICMP, DHCP, HTTP, HTTPS, RTP, RTSP,
FTP, SNMP, SMTP, UPnP, WS-Discovery, Zero Configuration, NTP, DDNS, RTMP |
|---|
| Security | Basic/Digest authentication, HTTPS, IP address filtering, User access log, TTA certification |
|---|
| Application programming interface | Truen protocol/SDK, ONVIF, PSIA, MPEG-TS |
|---|
Power / Operating Conditions| Power supply | DC 12V/3.0A, PoE(Power over Ethernet) : 802.3at |
|---|
| Power consumption | DC12V/PoE : Max 30W |
|---|
| Operating condition | -20°C ~ 70°C / Less than 90% RH |
|---|
| Storage condition | -50°C ~ 60°C / Less than 95% RH |
|---|
General| Certifications | IP67, IK10, KC |
|---|
| External devices | 1 x Sensor-In (dry contact, NO/NC)
1 x Alarm-Out (dry contact, NO)
1 x RS-485 port : Z/F control etc. |
|---|
| Edge storage | Micro SD/SDHC/SDXC (Max 512GB) |
|---|
| Color/Material | Body: Gray / Alluminium
Head: Gray / Alluminium |
|---|
| RAL code | White: TBD
Black: TBD |
|---|
| Dimension | Ø108 x 391.5mm |
|---|
| Weight | 1,750 g |
|---|
|
